| Parameter | Metric System (SI) | Imperial System |
|---|---|---|
| Nominal Force / Capacity | 100 kN (10 Tonnes) | 11.2 US Tons (10 Imperial Tons) |
| Stroke Capacity Position | 2 mm before bottom dead centre | 0.08″ before bottom dead centre |
| Standard Fixed Stroke | 50 mm | ~1.96″ |
| Adjustable Stroke Range | 10 mm – 50 mm | 0.39″ – 1.96″ |
| Stroke Frequency / Speed | 140 – 150 strokes per minute | 140 – 150 strokes per minute |
| Maximum Shut Height | 180 mm | 7.08″ |
| Shut Height Adjustment | 40 mm | 1.57″ |
| Throat Depth (Ram Center to Frame) | 140 mm | 5.51″ |
| Bolster Plate / Bed Size (W x D) | 360 mm x 240 mm | 14.1″ x 9.4″ |
| Bed Hole Dimension (Diameter) | 80 mm | 3.14″ |
| Slide / Ram Hole Dimension (Dia. x Depth) | 30 mm x 55 mm | 1.18″ x 2.16″ |
| Main Motor Power Requirement | 1.1 kW – 1.5 kW | 1.5 HP – 2.0 HP |
| Approximate Machine Weight | 500 kg – 600 kg | 1,100 lbs – 1,320 lbs |
