Drilling Capacity (Steel) 25 mm ~1"

Drilling Capacity (Cast Iron) 28 mm ~1.1"

Tapping Capacity M16 5/8"

Spindle Taper MT3 (MK3) MT3

Spindle Speeds 105 – 2,900 RPM (8 Speed Gearbox)

Quill Travel (Stroke) 135 mm 5.3"

Motor Power 0.65 kW / 0.9 kW ~0.9 HP / 1.2 HP (2-speed)

Column Diameter 100 mm 4"

Table Size 500 x 350 mm 19.7" x 13.8"

Net Weight ~190 kg ~420 lbs



Distinctive Features

​Geared Head Transmission: Unlike belt-driven drills, this uses a gearbox. Strands is famous for using a combination of steel and reinforced fiber gears. This design provides high torque while remaining significantly quieter than standard all-steel geared heads.

​Rotation: The drill head and the table arm can both rotate 360° around the column.

​Head Tilt: On the "U" (Universal) or Mill/Drill variants, the head can tilt 0-45°, but the standard S25M usually has a fixed vertical head with a rotating arm.

​Build: Known for a very rigid quill return spring and high-precision spindle runout.
