Table size                                                                         1450 x 400mm

Table T Slot                                                                      18mm x 3mm x 100mm

Maximum Table load                                                         200Kg’s

Table travel  (X, Y, Z)                                                        900mm / 450mm / 500mm

Distance between Spindle nose and Table                         50 - 550mm

Spindle type and diameter                                                 BT40 / 120mm

Spindle servo motor                                                          7.5Kw

Spindle speed                                                                   8000Rpm

Maximum Tool diameter                                                    80mm

Maximum Tool length - weight                                            200mm / 7Kg’s

Tool Changing time (arm type)                                           1.6sn

Rapid feed (X, Y, Z)                                                          15 / 15 / 12mt / min

Cutting speed                                                                   8mt / min

Weight                                                                              3000Kg’s

Tool Changer                                                                    Umbrella Type
