SMART NL2000 SLANT BED CNC LATHE WITH A FANUC OiTF PLUS CONTROL (MADE IN KOREA)
|
Swing over bed
|
570m
|
|
Swing over Cross Slide
|
370mm
|
|
Max. turning diameter
|
391mm
|
|
Max. turning length
|
560mm
|
|
X axis travel
|
230mm
|
|
Z axis travel
|
580mm
|
| |
|
|
Spindle:
|
|
|
Spindle Nose
|
ISO (DIN) A2-6
|
|
Spindle Bore
|
76mm
|
|
Max. bar capacity
|
67mm
|
|
Max. spindle speed
|
4500rpm
|
|
Spindle motor
|
11/18Kw
|
|
Hydraulic chuck size
|
8" 3 Jaw
|
|
Turret:
|
|
|
No of Tools
|
Hydraulic 12 Tools
|
|
Square tool holder
|
25 x 25mm
|
|
Max. boring bar diameter
|
40mm
|
| |
|
|
Tailstock:
|
|
|
Travel
|
450mm
|
|
Quill taper
|
4MT
|
|
Quill diameter
|
80mm
|
| |
|
|
Rapid feed rate – X - Axis
|
24M / min
|
|
Rapid feed rate – Z – Axis
|
30M / min
|
| |
|
|
Machine Dimensions
|
2793mm x 1551mm x 1902mm
|
|
Machine weight
|
3900Kg’s
|
Control Fanuc OiTF Plus
Standard Control Equipment supplied with the machine:
- Hydraulic Turret 12 station
- Foot pedal for chuck
- Soft Jaw x 1 set
- Heat exchanger for electric cabinet
- Work light
- Chip conveyor
- High powered coolant system
- Automatic lube system
- 6pc Boring Bar / U-Drill Holders (Ø40)
- 4pc OD Clamping Blocks (□25)
- 2pc OD Face Holders (□25)
- 1pc each size of Boring Bar Sleeve (Ø10,12,16,20,25,32)
- 1pc each size of U-Drill Sleeve (Ø20, 25, 32)
- 1pc each size of Drill Socket (M#2, MT#3)
- 3 sets of soft Jaws
- 1 set of Hard Jaws
- Toolbox & tools
- Operational manual
- Barfeeder Interface
